| Brand Name : | SANWEI |
| Supply Ability : | 100 Set/Sets per Quarter |
| Price : | $2,250.00/sets 1-4 sets |
1. Volume: 50 ~ 30000L
2. Material: SS304 , SS316 ; Carbon steel , Lined PTFE
3. Agitator: anchor , frame , paddle , multifunction etc.
4. Optional: heating or cooling
5. Type: single layer, double layer (jacketed type), limpet coil
type
6. Heating method: electric heating, steam heating, circulation oil
heating, infrared heating etc.
7. Warranty: 1 year
8. We support customization.
Model | 50L | 100L | 300L | 500L | 1000L | 2000L | 3000L | 5000L | |||||||
Mixing Motor Power | 0.75KW | 1.1KW | 2.2KW | 2.2KW | 4KW | 5.5KW | 7.5KW | 15KW | |||||||
Heating Motor Power | 8KW | 12KW | 24KW | 36KW | 48KW | 60KW | 75KW | 90KW | |||||||
Inner Plate Thickness | 5mm | 5mm | 5mm | 5mm | 6mm | 6mm | 8mm | 8mm | |||||||
Jacket Plate Thickness | 5mm | 5mm | 5mm | 5mm | 6mm | 6mm | 8mm | 8mm | |||||||
Material | SS304, SS316L, Carbon Steel; It also can be lined PTFE. | ||||||||||||||
Heating Type | electric heating, steam heating, oil circulation heating etc. | ||||||||||||||
Agitator | anchor, paddle, frame etc. | ||||||||||||||
Sealing Method | packing seal or mechanical seal (vacuum) | ||||||||||||||
Model | We still have more models. (6000l, 8000l, 10000l, 15000l, 20000l,
30000l etc.) | ||||||||||||||
Remarks | We support OEM | ||||||||||||||
|
|
